Temperature：-5~40℃
Supply Ability
10000 Piece/Pieces per Month
Packaging & Delivery
Standard package or according to customer's requirements
Port：NINGBO/SHANGHAI
Application
Construction Features the iron core is made of the rolled-up silicon-steel plate and the secondary coil is entwined onto the iron core evenly. There is neither primary bus nor device for fixing bus. And the whole iron core is secured by two clamps.
This product conforms to IEC60044-1 and GB1208-2006 standard.
Main Technical Parameter
Features:
1. Circuit requirements:
a. Frequency: 50 - 60Hz
b. Rated voltage: AC 660V
2. Production standard: IEC185
3. To test, control, display and record the operations of electricalEquipment
4 .To protect equipment against damage
5. Also used for mine transformer sets
|
Model |
Rated Current(A) |
Busbar Hole Dimension |
Rated Burden (VA) |
Accuracy Class |
Rated Voltage (V) |
Rated Frequency (Hz) |
|
BH-0.66-30 |
30/5A-300/5A |
30x10mm |
1.5-2.5 |
3.0~0.5 |
600 |
50/60 |
|
BH-0.66-40 |
150/5A-800/5A |
40x10mm |
5.0-1.0 |
1.0~0.5 |
600 |
50/60 |
|
BH-0.66-60 |
400/5A-1200/5A |
60x20mm |
5.0-1.0 |
1.0~0.5 |
600 |
50/60 |
|
BH-0.66-100 |
800/5A-3000/5A |
100x10mm |
15 |
1.0~0.5 |
600 |
50/60 |
