Product Description
|
Product name
|
TGM1N moulded case circuit breaker)
|
|
Ampere frame(A)
|
63 / 125 / 160 / 250 / 320 / 400 / 630 / 800 / 1250
|
|
Rated Operation Voltage(V)
|
AC 230 / 240 / 380 / 400 / 415 / 660 / 690
|
|
Rated Insulation Voltage(V)
|
800 / 1000
|
|
Isolation Function
|
Only 1P+N and 3P+N no isolation function
|
|
Mechanical Life
|
2500~8500
|
|
Protection Type
|
Distribution Protection ,Motor Protection
|
|
Tripping Type
|
Thermal Magnetic Trip, Single Magnetic Trip
|
|
Rated Frequency Hz
|
AC (50/60 Hz)
|
|
Rated Current In (A)
|
10~1250
|
|
Segmented Ability
|
L,M,H,R /5~100
|
|
Working Temperature
|
-5℃ ~ 40℃
|
|
Arc Distance(MM)
|
≤50 / ≤100
|
|
Electric Life
|
500~1500
|
